activity启动流程

ActivityStack.startPausingLocked() IApplicationThread.schudulePauseActivity() ActivityThread.sendMessage() ActivityThread.H.sendMessage(); ActivityThread.H.handleMessage() ActivityThread.handlePauseActivity() ActivityThread.performPauseActivity() Activity.performPause() Activity.onPause() ActivityManagerNative.getDefault().activityPaused(token) ActivityManagerService.activityPaused() ActivityStack.activityPausedLocked() ActivityStack.completePauseLocked() ActivityStack.resumeTopActivitiesLocked() ActivityStack.resumeTopActivityLocked() ActivityStack.resumeTopActivityInnerLocked() ActivityStack.startSpecificActivityLocked

好吧，方法比较多也比较乱，首先来看startPausingLocked方法：

final boolean startPausingLocked(boolean userLeaving, boolean uiSleeping, boolean resuming,
            boolean dontWait) {
        ...
        if (prev.app != null && prev.app.thread != null) {
            if (DEBUG_PAUSE) Slog.v(TAG_PAUSE, "Enqueueing pending pause: " + prev);
            try {
                EventLog.writeEvent(EventLogTags.AM_PAUSE_ACTIVITY,
                        prev.userId, System.identityHashCode(prev),
                        prev.shortComponentName);
                mService.updateUsageStats(prev, false);
                prev.app.thread.schedulePauseActivity(prev.appToken, prev.finishing,
                        userLeaving, prev.configChangeFlags, dontWait);
            } catch (Exception e) {
                // Ignore exception, if process died other code will cleanup.
                Slog.w(TAG, "Exception thrown during pause", e);
                mPausingActivity = null;
                mLastPausedActivity = null;
                mLastNoHistoryActivity = null;
            }
        } else {
            mPausingActivity = null;
            mLastPausedActivity = null;
            mLastNoHistoryActivity = null;
        }
        ...
    }

可以看到这里执行了pre.app.thread.schedulePauseActivity方法，通过分析不难发现这里的thread是一个IApplicationThread类型的对象，而在ActivityThread中也定义了一个ApplicationThread的类，其继承了IApplicationThread，并且都是Binder对象，不难看出这里的IAppcation是一个Binder的client端而ActivityThread中的ApplicationThread是一个Binder对象的server端，所以通过这里的thread.schedulePauseActivity实际上调用的就是ApplicationThread的schedulePauseActivity方法。

这里的ApplicationThread可以和ActivityManagerNative对于一下： 通过ActivityManagerNative --> ActivityManagerService实现了应用进程与SystemServer进程的通讯 通过AppicationThread <-- IApplicationThread实现了SystemServer进程与应用进程的通讯

然后我们继续看一下ActivityThread中schedulePauseActivity的具体实现：

public final void schedulePauseActivity(IBinder token, boolean finished,
                boolean userLeaving, int configChanges, boolean dontReport) {
            sendMessage(
                    finished ? H.PAUSE_ACTIVITY_FINISHING : H.PAUSE_ACTIVITY,
                    token,
                    (userLeaving ? 1 : 0) | (dontReport ? 2 : 0),
                    configChanges);
        }

发送了PAUSE_ACTIVITY_FINISHING消息，然后看一下sendMessage的实现方法：

private void sendMessage(int what, Object obj, int arg1, int arg2) {
        sendMessage(what, obj, arg1, arg2, false);
    }

调用了其重载方法：

private void sendMessage(int what, Object obj, int arg1, int arg2, boolean async) {
        if (DEBUG_MESSAGES) Slog.v(
            TAG, "SCHEDULE " + what + " " + mH.codeToString(what)
            + ": " + arg1 + " / " + obj);
        Message msg = Message.obtain();
        msg.what = what;
        msg.obj = obj;
        msg.arg1 = arg1;
        msg.arg2 = arg2;
        if (async) {
            msg.setAsynchronous(true);
        }
        mH.sendMessage(msg);
    }

最终调用了mH的sendMessage方法，mH是在ActivityThread中定义的一个Handler对象，主要处理SystemServer进程的消息，我们看一下其handleMessge方法的实现：

public void handleMessage(Message msg) {
            if (DEBUG_MESSAGES) Slog.v(TAG, ">>> handling: " + codeToString(msg.what));
            switch (msg.what) {
                ...
                case PAUSE_ACTIVITY_FINISHING:
                    Trace.traceBegin(Trace.TRACE_TAG_ACTIVITY_MANAGER, "activityPause");
                    handlePauseActivity((IBinder)msg.obj, true, (msg.arg1&1) != 0, msg.arg2,
                            (msg.arg1&1) != 0);
                    Trace.traceEnd(Trace.TRACE_TAG_ACTIVITY_MANAGER);
                    break;
                ...
}

可以发现其调用了handlePauseActivity方法：

private void handlePauseActivity(IBinder token, boolean finished,
            boolean userLeaving, int configChanges, boolean dontReport) {
        ActivityClientRecord r = mActivities.get(token);
        if (r != null) {
            //Slog.v(TAG, "userLeaving=" + userLeaving + " handling pause of " + r);
            if (userLeaving) {
                performUserLeavingActivity(r);
            }

            r.activity.mConfigChangeFlags |= configChanges;
            performPauseActivity(token, finished, r.isPreHoneycomb());

            // Make sure any pending writes are now committed.
            if (r.isPreHoneycomb()) {
                QueuedWork.waitToFinish();
            }

            // Tell the activity manager we have paused.
            if (!dontReport) {
                try {
                    ActivityManagerNative.getDefault().activityPaused(token);
                } catch (RemoteException ex) {
                }
            }
            mSomeActivitiesChanged = true;
        }
    }

然后在方法体内部通过调用performPauseActivity方法来实现对栈顶Activity的onPause生命周期方法的回调，可以具体看一下他的实现：

final Bundle performPauseActivity(IBinder token, boolean finished,
            boolean saveState) {
        ActivityClientRecord r = mActivities.get(token);
        return r != null ? performPauseActivity(r, finished, saveState) : null;
    }

然后调用其重载方法：

final Bundle performPauseActivity(ActivityClientRecord r, boolean finished,
            boolean saveState) {
        ...
        mInstrumentation.callActivityOnPause(r.activity);
        ...

        return !r.activity.mFinished && saveState ? r.state : null;
    }

这样回到了mInstrumentation的callActivityOnPuase方法：

public void callActivityOnPause(Activity activity) {
        activity.performPause();
    }

呵呵，原来最终回调到了Activity的performPause方法：

final void performPause() {
        mDoReportFullyDrawn = false;
        mFragments.dispatchPause();
        mCalled = false;
        onPause();
        mResumed = false;
        if (!mCalled && getApplicationInfo().targetSdkVersion
                >= android.os.Build.VERSION_CODES.GINGERBREAD) {
            throw new SuperNotCalledException(
                    "Activity " + mComponent.toShortString() +
                    " did not call through to super.onPause()");
        }
        mResumed = false;
    }

终于，太不容易了，回调到了Activity的onPause方法，哈哈，Activity生命周期中的第一个生命周期方法终于被我们找到了。。。。也就是说我们在启动一个Activity的时候最先被执行的是栈顶的Activity的onPause方法。记住这点吧，面试的时候经常会问到类似的问题。

然后回到我们的handlePauseActivity方法，在该方法的最后面执行了ActivityManagerNative.getDefault().activityPaused(token);方法，这是应用进程告诉服务进程，栈顶Activity已经执行完成onPause方法了，通过前面我们的分析，我们知道这句话最终会被ActivityManagerService的activityPaused方法执行。

@Override
    public final void activityPaused(IBinder token) {
        final long origId = Binder.clearCallingIdentity();
        synchronized(this) {
            ActivityStack stack = ActivityRecord.getStackLocked(token);
            if (stack != null) {
                stack.activityPausedLocked(token, false);
            }
        }
        Binder.restoreCallingIdentity(origId);
    }

可以发现，该方法内部会调用ActivityStack的activityPausedLocked方法，好吧，继续看一下activityPausedLocked方法的实现：

final void activityPausedLocked(IBinder token, boolean timeout) {
            ...
                if (DEBUG_STATES) Slog.v(TAG_STATES, "Moving to PAUSED: " + r
                        + (timeout ? " (due to timeout)" : " (pause complete)"));
                completePauseLocked(true);
            ...
    }

然后执行了completePauseLocked方法：

private void completePauseLocked(boolean resumeNext) {
        ...

        if (resumeNext) {
            final ActivityStack topStack = mStackSupervisor.getFocusedStack();
            if (!mService.isSleepingOrShuttingDown()) {
                mStackSupervisor.resumeTopActivitiesLocked(topStack, prev, null);
            } else {
                mStackSupervisor.checkReadyForSleepLocked();
                ActivityRecord top = topStack.topRunningActivityLocked(null);
                if (top == null || (prev != null && top != prev)) {
                    // If there are no more activities available to run,
                    // do resume anyway to start something.  Also if the top
                    // activity on the stack is not the just paused activity,
                    // we need to go ahead and resume it to ensure we complete
                    // an in-flight app switch.
                    mStackSupervisor.resumeTopActivitiesLocked(topStack, null, null);
                }
            }
        }
        ...
    }

经过了一系列的逻辑之后，又调用了resumeTopActivitiesLocked方法，又回到了第二步中解析的方法中了，这样经过 resumeTopActivitiesLocked --> ActivityStack.resumeTopActivityLocked() --> resumeTopActivityInnerLocked --> startSpecificActivityLocked 好吧，我们看一下startSpecificActivityLocked的具体实现：

void startSpecificActivityLocked(ActivityRecord r,
            boolean andResume, boolean checkConfig) {
        // Is this activity's application already running?
        ProcessRecord app = mService.getProcessRecordLocked(r.processName,
                r.info.applicationInfo.uid, true);

        r.task.stack.setLaunchTime(r);

        if (app != null && app.thread != null) {
            try {
                if ((r.info.flags&ActivityInfo.FLAG_MULTIPROCESS) == 0
                        || !"android".equals(r.info.packageName)) {
                    // Don't add this if it is a platform component that is marked
                    // to run in multiple processes, because this is actually
                    // part of the framework so doesn't make sense to track as a
                    // separate apk in the process.
                    app.addPackage(r.info.packageName, r.info.applicationInfo.versionCode,
                            mService.mProcessStats);
                }
                realStartActivityLocked(r, app, andResume, checkConfig);
                return;
            } catch (RemoteException e) {
                Slog.w(TAG, "Exception when starting activity "
                        + r.intent.getComponent().flattenToShortString(), e);
            }

            // If a dead object exception was thrown -- fall through to
            // restart the application.
        }

        mService.startProcessLocked(r.processName, r.info.applicationInfo, true, 0,
                "activity", r.intent.getComponent(), false, false, true);
    }

可以发现在这个方法中，首先会判断一下需要启动的Activity所需要的应用进程是否已经启动，若启动的话，则直接调用realStartAtivityLocked方法，否则调用startProcessLocked方法，用于启动应用进程。 这样关于启动Activity时的第三步骤就已经执行完成了，这里主要是实现了对栈顶Activity执行onPause 方法，而这个方法首先判断需要启动的Activity所属的进程是否已经启动，若已经启动则直接调用启动Activity的方法，否则将先启动Activity的应用进程，然后在启动该Activity。

四：启动Activity所属的应用进程

关于如何启动应用进程，前面的一篇文章已经做了介绍，可参考： android源码解析之（十一）-->应用进程启动流程 这里在简单的介绍一下

ActivityManagerService.startProcessLocked() Process.start() ActivityThread.main() ActivityThread.attach() ActivityManagerNative.getDefault().attachApplication() ActivityManagerService.attachApplication()

好吧，首先看一下startProcessLocked()方法的具体实现：

private final void startProcessLocked(ProcessRecord app,
            String hostingType, String hostingNameStr) {
        startProcessLocked(app, hostingType, hostingNameStr, null /* abiOverride */,
                null /* entryPoint */, null /* entryPointArgs */);
    }

然后回调了其重载的startProcessLocked方法：

private final void startProcessLocked(ProcessRecord app, String hostingType,
            String hostingNameStr, String abiOverride, String entryPoint, String[] entryPointArgs) {
            ...
            boolean isActivityProcess = (entryPoint == null);
            if (entryPoint == null) entryPoint = "android.app.ActivityThread";
            Trace.traceBegin(Trace.TRACE_TAG_ACTIVITY_MANAGER, "Start proc: " +
                    app.processName);
            checkTime(startTime, "startProcess: asking zygote to start proc");
            Process.ProcessStartResult startResult = Process.start(entryPoint,
                    app.processName, uid, uid, gids, debugFlags, mountExternal,
                    app.info.targetSdkVersion, app.info.seinfo, requiredAbi, instructionSet,
                    app.info.dataDir, entryPointArgs);
            checkTime(startTime, "startProcess: returned from zygote!");
            ...
    }

可以发现其经过一系列的初始化操作之后调用了Process.start方法，并且传入了启动的类名“android.app.ActivityThread”:

public static final ProcessStartResult start(final String processClass,
                                  final String niceName,
                                  int uid, int gid, int[] gids,
                                  int debugFlags, int mountExternal,
                                  int targetSdkVersion,
                                  String seInfo,
                                  String abi,
                                  String instructionSet,
                                  String appDataDir,
                                  String[] zygoteArgs) {
        try {
            return startViaZygote(processClass, niceName, uid, gid, gids,
                    debugFlags, mountExternal, targetSdkVersion, seInfo,
                    abi, instructionSet, appDataDir, zygoteArgs);
        } catch (ZygoteStartFailedEx ex) {
            Log.e(LOG_TAG,
                    "Starting VM process through Zygote failed");
            throw new RuntimeException(
                    "Starting VM process through Zygote failed", ex);
        }
    }

然后调用了startViaZygote方法：

private static ProcessStartResult startViaZygote(final String processClass,
                                  final String niceName,
                                  final int uid, final int gid,
                                  final int[] gids,
                                  int debugFlags, int mountExternal,
                                  int targetSdkVersion,
                                  String seInfo,
                                  String abi,
                                  String instructionSet,
                                  String appDataDir,
                                  String[] extraArgs)
                                  throws ZygoteStartFailedEx {
        synchronized(Process.class) {
            ...

            return zygoteSendArgsAndGetResult(openZygoteSocketIfNeeded(abi), argsForZygote);
        }
    }

继续查看一下zygoteSendArgsAndGetResult方法的实现：

private static ProcessStartResult zygoteSendArgsAndGetResult(
            ZygoteState zygoteState, ArrayList<String> args)
            throws ZygoteStartFailedEx {
        try {
            /**
             * See com.android.internal.os.ZygoteInit.readArgumentList()
             * Presently the wire format to the zygote process is:
             * a) a count of arguments (argc, in essence)
             * b) a number of newline-separated argument strings equal to count
             *
             * After the zygote process reads these it will write the pid of
             * the child or -1 on failure, followed by boolean to
             * indicate whether a wrapper process was used.
             */
            final BufferedWriter writer = zygoteState.writer;
            final DataInputStream inputStream = zygoteState.inputStream;

            writer.write(Integer.toString(args.size()));
            writer.newLine();

            int sz = args.size();
            for (int i = 0; i < sz; i++) {
                String arg = args.get(i);
                if (arg.indexOf('\n') >= 0) {
                    throw new ZygoteStartFailedEx(
                            "embedded newlines not allowed");
                }
                writer.write(arg);
                writer.newLine();
            }

            writer.flush();

            // Should there be a timeout on this?
            ProcessStartResult result = new ProcessStartResult();
            result.pid = inputStream.readInt();
            if (result.pid < 0) {
                throw new ZygoteStartFailedEx("fork() failed");
            }
            result.usingWrapper = inputStream.readBoolean();
            return result;
        } catch (IOException ex) {
            zygoteState.close();
            throw new ZygoteStartFailedEx(ex);
        }
    }

可以发现其最终调用了Zygote并通过socket通信的方式让Zygote进程fork除了一个新的进程，并根据我们刚刚传递的"android.app.ActivityThread"字符串，反射出该对象并执行ActivityThread的main方法。这样我们所要启动的应用进程这时候其实已经启动了，但是还没有执行相应的初始化操作。

为什么我们平时都将ActivityThread称之为ui线程或者是主线程，这里可以看出，应用进程被创建之后首先执行的是ActivityThread的main方法，所以我们将ActivityThread成为主线程。

好了，这时候我们看一下ActivityThread的main方法的实现逻辑。

public static void main(String[] args) {
        ...
        Process.setArgV0("<pre-initialized>");

        Looper.prepareMainLooper();

        ActivityThread thread = new ActivityThread();
        thread.attach(false);

        if (sMainThreadHandler == null) {
            sMainThreadHandler = thread.getHandler();
        }

        if (false) {
            Looper.myLooper().setMessageLogging(new
                    LogPrinter(Log.DEBUG, "ActivityThread"));
        }

        // End of event ActivityThreadMain.
        Trace.traceEnd(Trace.TRACE_TAG_ACTIVITY_MANAGER);
        Looper.loop();

        throw new RuntimeException("Main thread loop unexpectedly exited");
    }

在main方法中主要执行了一些初始化的逻辑，并且创建了一个UI线程消息队列，这也就是为什么我们可以在主线程中随意的创建Handler而不会报错的原因，这里提出一个问题，大家可以思考一下：子线程可以创建Handler么？可以的话应该怎么做？ 然后执行了ActivityThread的attach方法，这里我们看一下attach方法执行了那些逻辑操作。

private void attach(boolean system) {
    ...
    final IActivityManager mgr = ActivityManagerNative.getDefault();
            try {
                mgr.attachApplication(mAppThread);
            } catch (RemoteException ex) {
                // Ignore
            }
    ...
}

刚刚我们已经分析过ActivityManagerNative是ActivityManagerService的Binder client，所以这里调用了attachApplication实际上就是通过Binder机制调用了ActivityManagerService的attachApplication，具体调用的过程，我们看一下ActivityManagerService是如何实现的：

@Override
    public final void attachApplication(IApplicationThread thread) {
        synchronized (this) {
            int callingPid = Binder.getCallingPid();
            final long origId = Binder.clearCallingIdentity();
            attachApplicationLocked(thread, callingPid);
            Binder.restoreCallingIdentity(origId);
        }
    }

可以发现其回调了attachApplicationLocked方法，我们看一下这个方法的实现逻辑。

private final boolean attachApplicationLocked(IApplicationThread thread,
            int pid) {

        ...
        // See if the top visible activity is waiting to run in this process...
        if (normalMode) {
            try {
                if (mStackSupervisor.attachApplicationLocked(app)) {
                    didSomething = true;
                }
            } catch (Exception e) {
                Slog.wtf(TAG, "Exception thrown launching activities in " + app, e);
                badApp = true;
            }
        }
        ...

        return true;
    }

该方法执行了一系列的初始化操作，这样我们整个应用进程已经启动起来了。终于可以开始activity的启动逻辑了，O(∩_∩)O哈哈~

五：执行启动Acitivity

ActivityStackSupervisor.attachApplicationLocked() ActivityStackSupervisor.realStartActivityLocked() IApplicationThread.scheduleLauncherActivity() ActivityThread.sendMessage() ActivityThread.H.sendMessage() ActivityThread.H.handleMessage() ActivityThread.handleLauncherActivity() ActivityThread.performLauncherActivity() Instrumentation.callActivityOnCreate() Activity.onCreate() ActivityThread.handleResumeActivity() ActivityThread.performResumeActivity() Activity.performResume() Instrumentation.callActivityOnResume() Activity.onResume() ActivityManagerNative.getDefault().activityResumed(token)

首先看一下attachApplicationLocked方法的实现：

boolean attachApplicationLocked(ProcessRecord app) throws RemoteException {
        final String processName = app.processName;
        boolean didSomething = false;
        for (int displayNdx = mActivityDisplays.size() - 1; displayNdx >= 0; --displayNdx) {
            ArrayList<ActivityStack> stacks = mActivityDisplays.valueAt(displayNdx).mStacks;
            for (int stackNdx = stacks.size() - 1; stackNdx >= 0; --stackNdx) {
                final ActivityStack stack = stacks.get(stackNdx);
                if (!isFrontStack(stack)) {
                    continue;
                }
                ActivityRecord hr = stack.topRunningActivityLocked(null);
                if (hr != null) {
                    if (hr.app == null && app.uid == hr.info.applicationInfo.uid
                            && processName.equals(hr.processName)) {
                        try {
                            if (realStartActivityLocked(hr, app, true, true)) {
                                didSomething = true;
                            }
                        } catch (RemoteException e) {
                            Slog.w(TAG, "Exception in new application when starting activity "
                                  + hr.intent.getComponent().flattenToShortString(), e);
                            throw e;
                        }
                    }
                }
            }
        }
        if (!didSomething) {
            ensureActivitiesVisibleLocked(null, 0);
        }
        return didSomething;
    }

可以发现其内部调用了realStartActivityLocked方法，通过名字可以知道这个方法应该就是用来启动Activity的，看一下这个方法的实现逻辑：

final boolean realStartActivityLocked(ActivityRecord r,
            ProcessRecord app, boolean andResume, boolean checkConfig)
            throws RemoteException {

        ...
            app.forceProcessStateUpTo(mService.mTopProcessState);
            app.thread.scheduleLaunchActivity(new Intent(r.intent), r.appToken,
                    System.identityHashCode(r), r.info, new Configuration(mService.mConfiguration),
                    new Configuration(stack.mOverrideConfig), r.compat, r.launchedFromPackage,
                    task.voiceInteractor, app.repProcState, r.icicle, r.persistentState, results,
                    newIntents, !andResume, mService.isNextTransitionForward(), profilerInfo);
        ...
        return true;
    }

可以发现与第三步执行栈顶Activity onPause时类似，这里也是通过调用IApplicationThread的方法实现的，这里调用的是scheduleLauncherActivity方法，所以真正执行的是ActivityThread中的scheduleLauncherActivity，所以我们看一下ActivityThread中的scheduleLauncherActivity的实现：

@Override
        public final void scheduleLaunchActivity(Intent intent, IBinder token, int ident,
                ActivityInfo info, Configuration curConfig, Configuration overrideConfig,
                CompatibilityInfo compatInfo, String referrer, IVoiceInteractor voiceInteractor,
                int procState, Bundle state, PersistableBundle persistentState,
                List<ResultInfo> pendingResults, List<ReferrerIntent> pendingNewIntents,
                boolean notResumed, boolean isForward, ProfilerInfo profilerInfo) {

            updateProcessState(procState, false);

            ActivityClientRecord r = new ActivityClientRecord();

            r.token = token;
            r.ident = ident;
            r.intent = intent;
            r.referrer = referrer;
            r.voiceInteractor = voiceInteractor;
            r.activityInfo = info;
            r.compatInfo = compatInfo;
            r.state = state;
            r.persistentState = persistentState;

            r.pendingResults = pendingResults;
            r.pendingIntents = pendingNewIntents;

            r.startsNotResumed = notResumed;
            r.isForward = isForward;

            r.profilerInfo = profilerInfo;

            r.overrideConfig = overrideConfig;
            updatePendingConfiguration(curConfig);

            sendMessage(H.LAUNCH_ACTIVITY, r);
        }

好吧，还是那套逻辑，ActivityThread接收到SystemServer进程的消息之后会通过其内部的Handler对象分发消息，经过一系列的分发之后调用了ActivityThread的handleLaunchActivity方法：

private void handleLaunchActivity(ActivityClientRecord r, Intent customIntent) {

        Activity a = performLaunchActivity(r, customIntent);

        if (a != null) {
            r.createdConfig = new Configuration(mConfiguration);
            Bundle oldState = r.state;
            handleResumeActivity(r.token, false, r.isForward,
                    !r.activity.mFinished && !r.startsNotResumed);


        }
        ...
    }

可以发现这里调用了performLauncherActivity，看名字应该就是执行Activity的启动操作了。。。

private Activity performLaunchActivity(ActivityClientRecord r, Intent customIntent) {
        ...

Activity activity = null;
        try {
            java.lang.ClassLoader cl = r.packageInfo.getClassLoader();
            activity = mInstrumentation.newActivity(
                    cl, component.getClassName(), r.intent);
            StrictMode.incrementExpectedActivityCount(activity.getClass());
            r.intent.setExtrasClassLoader(cl);
            r.intent.prepareToEnterProcess();
            if (r.state != null) {
                r.state.setClassLoader(cl);
            }
        } catch (Exception e) {
            if (!mInstrumentation.onException(activity, e)) {
                throw new RuntimeException(
                    "Unable to instantiate activity " + component
                    + ": " + e.toString(), e);
            }
        }
        ...

        activity.mCalled = false;
        if (r.isPersistable()) {
           mInstrumentation.callActivityOnCreate(activity, r.state, r.persistentState);
        } else {
           mInstrumentation.callActivityOnCreate(activity, r.state);
        }
        ...
        if (!r.activity.mFinished) {
                    activity.performStart();
                    r.stopped = false;
                }
        ...
        return activity;
    }

可以发现这里我们需要的Activity对象终于是创建出来了，而且他是以反射的机制创建的，现在还不太清楚为啥google要以反射的方式创建Activity，先不看这些，然后在代码中其调用Instrumentation的callActivityOnCreate方法。

public void callActivityOnCreate(Activity activity, Bundle icicle,
            PersistableBundle persistentState) {
        prePerformCreate(activity);
        activity.performCreate(icicle);
        postPerformCreate(activity);
    }

然后执行activity的performCreate方法。。。。好吧，都转晕了。。。

final void performCreate(Bundle icicle) {
        onCreate(icicle);
        mActivityTransitionState.readState(icicle);
        performCreateCommon();
    }

O(∩_∩)O哈哈~，第二个生命周期方法出来了，onCreate方法。。。。

在回到我们的performLaunchActivity方法，其在调用了mInstrumentation.callActivityOnCreate方法之后又调用了activity.performStart();方法，好吧，看一下他的实现方式：

final void performStart() {
        mActivityTransitionState.setEnterActivityOptions(this, getActivityOptions());
        mFragments.noteStateNotSaved();
        mCalled = false;
        mFragments.execPendingActions();
        mInstrumentation.callActivityOnStart(this);
        if (!mCalled) {
            throw new SuperNotCalledException(
                "Activity " + mComponent.toShortString() +
                " did not call through to super.onStart()");
        }
        mFragments.dispatchStart();
        mFragments.reportLoaderStart();
        mActivityTransitionState.enterReady(this);
    }

好吧，还是通过Instrumentation调用callActivityOnStart方法：

public void callActivityOnStart(Activity activity) {
        activity.onStart();
    }

然后是直接调用activity的onStart方法，第三个生命周期方法出现了，O(∩_∩)O哈哈~

还是回到我们刚刚的handleLaunchActivity方法，在调用完performLaunchActivity方法之后，其有吊用了handleResumeActivity方法，好吧，看名字应该是回调Activity的onResume方法的。

final void handleResumeActivity(IBinder token,
            boolean clearHide, boolean isForward, boolean reallyResume) {
        // If we are getting ready to gc after going to the background, well
        // we are back active so skip it.
        unscheduleGcIdler();
        mSomeActivitiesChanged = true;

        // TODO Push resumeArgs into the activity for consideration
        ActivityClientRecord r = performResumeActivity(token, clearHide);

        if (r != null) {
            final Activity a = r.activity;

            if (localLOGV) Slog.v(
                TAG, "Resume " + r + " started activity: " +
                a.mStartedActivity + ", hideForNow: " + r.hideForNow
                + ", finished: " + a.mFinished);

            final int forwardBit = isForward ?
                    WindowManager.LayoutParams.SOFT_INPUT_IS_FORWARD_NAVIGATION : 0;

            // If the window hasn't yet been added to the window manager,
            // and this guy didn't finish itself or start another activity,
            // then go ahead and add the window.
            boolean willBeVisible = !a.mStartedActivity;
            if (!willBeVisible) {
                try {
                    willBeVisible = ActivityManagerNative.getDefault().willActivityBeVisible(
                            a.getActivityToken());
                } catch (RemoteException e) {
                }
            }
            if (r.window == null && !a.mFinished && willBeVisible) {
                r.window = r.activity.getWindow();
                View decor = r.window.getDecorView();
                decor.setVisibility(View.INVISIBLE);
                ViewManager wm = a.getWindowManager();
                WindowManager.LayoutParams l = r.window.getAttributes();
                a.mDecor = decor;
                l.type = WindowManager.LayoutParams.TYPE_BASE_APPLICATION;
                l.softInputMode |= forwardBit;
                if (a.mVisibleFromClient) {
                    a.mWindowAdded = true;
                    wm.addView(decor, l);
                }

            // If the window has already been added, but during resume
            // we started another activity, then don't yet make the
            // window visible.
            } else if (!willBeVisible) {
                if (localLOGV) Slog.v(
                    TAG, "Launch " + r + " mStartedActivity set");
                r.hideForNow = true;
            }

            // Get rid of anything left hanging around.
            cleanUpPendingRemoveWindows(r);

            // The window is now visible if it has been added, we are not
            // simply finishing, and we are not starting another activity.
            if (!r.activity.mFinished && willBeVisible
                    && r.activity.mDecor != null && !r.hideForNow) {
                if (r.newConfig != null) {
                    r.tmpConfig.setTo(r.newConfig);
                    if (r.overrideConfig != null) {
                        r.tmpConfig.updateFrom(r.overrideConfig);
                    }
                    if (DEBUG_CONFIGURATION) Slog.v(TAG, "Resuming activity "
                            + r.activityInfo.name + " with newConfig " + r.tmpConfig);
                    performConfigurationChanged(r.activity, r.tmpConfig);
                    freeTextLayoutCachesIfNeeded(r.activity.mCurrentConfig.diff(r.tmpConfig));
                    r.newConfig = null;
                }
                if (localLOGV) Slog.v(TAG, "Resuming " + r + " with isForward="
                        + isForward);
                WindowManager.LayoutParams l = r.window.getAttributes();
                if ((l.softInputMode
                        & WindowManager.LayoutParams.SOFT_INPUT_IS_FORWARD_NAVIGATION)
                        != forwardBit) {
                    l.softInputMode = (l.softInputMode
                            & (~WindowManager.LayoutParams.SOFT_INPUT_IS_FORWARD_NAVIGATION))
                            | forwardBit;
                    if (r.activity.mVisibleFromClient) {
                        ViewManager wm = a.getWindowManager();
                        View decor = r.window.getDecorView();
                        wm.updateViewLayout(decor, l);
                    }
                }
                r.activity.mVisibleFromServer = true;
                mNumVisibleActivities++;
                if (r.activity.mVisibleFromClient) {
                    r.activity.makeVisible();
                }
            }

            if (!r.onlyLocalRequest) {
                r.nextIdle = mNewActivities;
                mNewActivities = r;
                if (localLOGV) Slog.v(
                    TAG, "Scheduling idle handler for " + r);
                Looper.myQueue().addIdleHandler(new Idler());
            }
            r.onlyLocalRequest = false;

            // Tell the activity manager we have resumed.
            if (reallyResume) {
                try {
                    ActivityManagerNative.getDefault().activityResumed(token);
                } catch (RemoteException ex) {
                }
            }

        } else {
            // If an exception was thrown when trying to resume, then
            // just end this activity.
            try {
                ActivityManagerNative.getDefault()
                    .finishActivity(token, Activity.RESULT_CANCELED, null, false);
            } catch (RemoteException ex) {
            }
        }
    }

可以发现其resumeActivity的逻辑调用到了performResumeActivity方法，我们来看一下performResumeActivity是如何实现的。

public final ActivityClientRecord performResumeActivity(IBinder token,
            boolean clearHide) {
        ActivityClientRecord r = mActivities.get(token);
        if (localLOGV) Slog.v(TAG, "Performing resume of " + r
                + " finished=" + r.activity.mFinished);
        if (r != null && !r.activity.mFinished) {
            if (clearHide) {
                r.hideForNow = false;
                r.activity.mStartedActivity = false;
            }
            try {
                r.activity.onStateNotSaved();
                r.activity.mFragments.noteStateNotSaved();
                if (r.pendingIntents != null) {
                    deliverNewIntents(r, r.pendingIntents);
                    r.pendingIntents = null;
                }
                if (r.pendingResults != null) {
                    deliverResults(r, r.pendingResults);
                    r.pendingResults = null;
                }
                r.activity.performResume();

                EventLog.writeEvent(LOG_AM_ON_RESUME_CALLED,
                        UserHandle.myUserId(), r.activity.getComponentName().getClassName());

                r.paused = false;
                r.stopped = false;
                r.state = null;
                r.persistentState = null;
            } catch (Exception e) {
                if (!mInstrumentation.onException(r.activity, e)) {
                    throw new RuntimeException(
                        "Unable to resume activity "
                        + r.intent.getComponent().toShortString()
                        + ": " + e.toString(), e);
                }
            }
        }
        return r;
    }

在方法体中，最终调用了r.activity.performResume();方法，好吧，这个方法是Activity中定义的方法，我们需要在Activity中查看这个方法的具体实现：

final void performResume() {
        ...
        mInstrumentation.callActivityOnResume(this);
        ...
    }

好吧，又是熟悉的味道，通过Instrumentation来调用了callActivityOnResume方法。。。

public void callActivityOnResume(Activity activity) {
        activity.mResumed = true;
        activity.onResume();

        if (mActivityMonitors != null) {
            synchronized (mSync) {
                final int N = mActivityMonitors.size();
                for (int i=0; i<N; i++) {
                    final ActivityMonitor am = mActivityMonitors.get(i);
                    am.match(activity, activity, activity.getIntent());
                }
            }
        }
    }

O(∩_∩)O哈哈~，第四个生命周期方法出现了，onResume方法。。。

终于回调onResume方法了，这时候我们的界面应该已经展示出来了，照理来说我们的Activity应该已经启动完成了，但是还没有，哈哈，别着急。

有一个问题，Activity a 启动 Activity b 会触发那些生命周期方法？ 你可能会回答？b的onCreate onStart方法，onResume方法 a的onPause方法和onStop方法，咦？对了onStop方法还没回调呢，O(∩_∩)O哈哈~，对了缺少的就是对onStop方法的回调啊。

好吧，具体的逻辑我们下一步再说

六：栈顶Activity执行onStop方法

Looper.myQueue().addIdleHandler(new Idler());

private class Idler implements MessageQueue.IdleHandler {
        @Override
        public final boolean queueIdle() {
            ActivityClientRecord a = mNewActivities;
            boolean stopProfiling = false;
            if (mBoundApplication != null && mProfiler.profileFd != null
                    && mProfiler.autoStopProfiler) {
                stopProfiling = true;
            }
            if (a != null) {
                mNewActivities = null;
                IActivityManager am = ActivityManagerNative.getDefault();
                ActivityClientRecord prev;
                do {
                    if (localLOGV) Slog.v(
                        TAG, "Reporting idle of " + a +
                        " finished=" +
                        (a.activity != null && a.activity.mFinished));
                    if (a.activity != null && !a.activity.mFinished) {
                        try {
                            am.activityIdle(a.token, a.createdConfig, stopProfiling);
                            a.createdConfig = null;
                        } catch (RemoteException ex) {
                            // Ignore
                        }
                    }
                    prev = a;
                    a = a.nextIdle;
                    prev.nextIdle = null;
                } while (a != null);
            }
            if (stopProfiling) {
                mProfiler.stopProfiling();
            }
            ensureJitEnabled();
            return false;
        }
    }

@Override
    public final void activityIdle(IBinder token, Configuration config, boolean stopProfiling) {
        final long origId = Binder.clearCallingIdentity();
        synchronized (this) {
            ActivityStack stack = ActivityRecord.getStackLocked(token);
            if (stack != null) {
                ActivityRecord r =
                        mStackSupervisor.activityIdleInternalLocked(token, false, config);
                if (stopProfiling) {
                    if ((mProfileProc == r.app) && (mProfileFd != null)) {
                        try {
                            mProfileFd.close();
                        } catch (IOException e) {
                        }
                        clearProfilerLocked();
                    }
                }
            }
        }
        Binder.restoreCallingIdentity(origId);
    }

final ActivityRecord activityIdleInternalLocked(final IBinder token, boolean fromTimeout,
            Configuration config) {
        ...

        // Stop any activities that are scheduled to do so but have been
        // waiting for the next one to start.
        for (int i = 0; i < NS; i++) {
            r = stops.get(i);
            final ActivityStack stack = r.task.stack;
            if (stack != null) {
                if (r.finishing) {
                    stack.finishCurrentActivityLocked(r, ActivityStack.FINISH_IMMEDIATELY, false);
                } else {
                    stack.stopActivityLocked(r);
                }
            }
        }

        ...

        return r;
    }

final void stopActivityLocked(ActivityRecord r) {
        if (DEBUG_SWITCH) Slog.d(TAG_SWITCH, "Stopping: " + r);
        if ((r.intent.getFlags()&Intent.FLAG_ACTIVITY_NO_HISTORY) != 0
                || (r.info.flags&ActivityInfo.FLAG_NO_HISTORY) != 0) {
            ...
                r.app.thread.scheduleStopActivity(r.appToken, r.visible, r.configChangeFlags);
             ...
        }
    }

public final void scheduleStopActivity(IBinder token, boolean showWindow,
                int configChanges) {
           sendMessage(
                showWindow ? H.STOP_ACTIVITY_SHOW : H.STOP_ACTIVITY_HIDE,
                token, 0, configChanges);
        }

private void handleStopActivity(IBinder token, boolean show, int configChanges) {
        ...
        performStopActivityInner(r, info, show, true);
        ...
    }

private void performStopActivityInner(ActivityClientRecord r,
            StopInfo info, boolean keepShown, boolean saveState) {
            ...
            // Next have the activity save its current state and managed dialogs...
            if (!r.activity.mFinished && saveState) {
                if (r.state == null) {
                    callCallActivityOnSaveInstanceState(r);
                }
            }

            if (!keepShown) {
                try {
                    // Now we are idle.
                    r.activity.performStop();
                } catch (Exception e) {
                    if (!mInstrumentation.onException(r.activity, e)) {
                        throw new RuntimeException(
                                "Unable to stop activity "
                                + r.intent.getComponent().toShortString()
                                + ": " + e.toString(), e);
                    }
                }
                r.stopped = true;
            }
        }
    }

private void callCallActivityOnSaveInstanceState(ActivityClientRecord r) {
        r.state = new Bundle();
        r.state.setAllowFds(false);
        if (r.isPersistable()) {
            r.persistentState = new PersistableBundle();
            mInstrumentation.callActivityOnSaveInstanceState(r.activity, r.state,
                    r.persistentState);
        } else {
            mInstrumentation.callActivityOnSaveInstanceState(r.activity, r.state);
        }
    }

public void callActivityOnSaveInstanceState(Activity activity, Bundle outState,
            PersistableBundle outPersistentState) {
        activity.performSaveInstanceState(outState, outPersistentState);
    }

final void performSaveInstanceState(Bundle outState) {
        onSaveInstanceState(outState);
        saveManagedDialogs(outState);
        mActivityTransitionState.saveState(outState);
        if (DEBUG_LIFECYCLE) Slog.v(TAG, "onSaveInstanceState " + this + ": " + outState);
    }

final void performStop() {
        mDoReportFullyDrawn = false;
        mFragments.doLoaderStop(mChangingConfigurations /*retain*/);

        if (!mStopped) {
            if (mWindow != null) {
                mWindow.closeAllPanels();
            }

            if (mToken != null && mParent == null) {
                WindowManagerGlobal.getInstance().setStoppedState(mToken, true);
            }

            mFragments.dispatchStop();

            mCalled = false;
            mInstrumentation.callActivityOnStop(this);
            if (!mCalled) {
                throw new SuperNotCalledException(
                    "Activity " + mComponent.toShortString() +
                    " did not call through to super.onStop()");
            }

            synchronized (mManagedCursors) {
                final int N = mManagedCursors.size();
                for (int i=0; i<N; i++) {
                    ManagedCursor mc = mManagedCursors.get(i);
                    if (!mc.mReleased) {
                        mc.mCursor.deactivate();
                        mc.mReleased = true;
                    }
                }
            }

            mStopped = true;
        }
        mResumed = false;
    }

public void callActivityOnStop(Activity activity) {
        activity.onStop();
    }
